StarTech.com 4 Port Rack Mountable USB KVM Switch with Audio & USB Hub

SKU
SV431USBAEGB
Login for pricing
In stock
StarTech.com USB KVM Switch With Audio - KVM / Audio / USB Switch - USB - 4 Ports - 1 Local User - 1U (SV431USBAEGB)
Share keyboard, mouse, speakers and a VGA display between four multimedia computers

This Rack Mountable USB KVM Switch supports high resolution video applications (up to 1920x1440 pixels supported) and audio switching between connected computers, and provides an integrated USB 2.0 hub that lets the selected computer have access shared high speed USB peripherals.
Providing control of up to four computers from a single USB keyboard and mouse peripheral set, the switch features a sturdy all metal chassis and can be rackmounted in a server rack/cabinet using an optional Rackmount Bracket kit (SV431RACK) - minimizing clutter and saving space.

This product is TAA compliant and is backed by a Startech.com 3 year warranty with lifetine technical support.

The StarTech.com Advantage
SKU SV431USBAEGB
EAN 0065030830768
Specification
Ports & interfaces
Console ports3.5mm headphone, 3.5mm mic
Number of microphone inputs1
Number of computers controlled4
Keyboard port typeUSB
Mouse port typeUSB
Video port typeVGA
Headphone outputs1
USB hubYes
USB 2.0 Type-A hub ports quantity4
Performance
Daisy chainNo
Maximum resolution1920 x 1440 pixels
Number of users1 user(s)
Technical details
Product colourBlack
Rack mountingYes
On Screen Display (OSD)No
Number of users1 user(s)
Hot keysNo
IP controlNo
USB hubYes
Compliance certificatesCE, RoHS
Design
Product colourBlack
Rack mountingYes
Hot keysNo
Rack capacity1U
Housing materialSteel
Display
Built-in displayNo
On Screen Display (OSD)No
Power
Input current0.4 A
Output current2 A
Output voltage5 V
Power consumption (typical)10 W
External power adapterYes
Input voltage100 - 240 V
Video
Maximum resolution1920 x 1440 pixels
Sustainability
Compliance certificatesCE, RoHS
Weight & dimensions
Width220 mm
Depth130 mm
Height44 mm
Weight1 kg
Package width90 mm
Package depth410 mm
Package height215 mm
Package weight1.7 kg
Packaging data
Package width90 mm
Package depth410 mm
Package height215 mm
Package weight1.7 kg
Packaging content
Rubber feetYes
ManualYes
AC adapter includedYes
Other features
IP controlNo
Hot keysNo
Logistics data
Master (outer) case width555 mm
Master (outer) case length430 mm
Master (outer) case height248 mm
Products per master (outer) case6 pc(s)
Harmonized System (HS) code85176200
Manufacturer StarTech.com
PDF Url https://objects.icecat.biz/objects/mm
In Stock Y
