DELL S-Series S5248F-ON Managed L2/L3 1U Black

SKU

210-APEX

Skip to the beginning of the images gallery

48 x 25GbE SFP28, 4 x 100GbE QSFP28, 2 x 100GbE QSFP-DD, IO - PSU, 2 x PSU, OS10

48 x SFP28
4 x QSFP28
2 x QSFP-DD
OS10

More Information
Power over ethernet	No
Stackable	Yes
Ports type	N
SKU	210-APEX
EAN	5397184223130
Manufacturer	DELL
Availability	In Stock
Product Family	S-Series
PDF URLs	View PDF View PDF View PDF View PDF View PDF View PDF View PDF View PDF View PDF View PDF View PDF

Reasons To Buy

Innovative data center architectural agility with 25/40/50/100GbE switches

Gain the flexibility to transform your data centers with high-capacity network fabrics that are easy to deploy, cost-effective and provide a clear path to a software-defined data center. They offer:

- High density for 25/40/50/100GbE deployments in top-of-rack, middle-of-row, and end-of-row deployments
- A choice of S5048F-ON, S5148F-ON, S5248F-ON, S5296F-ON and S5232F-ON 25 &100GbE, S6000-ON and S6010-ON 40GbE switches and the S6100-ON 10/25/40/50/100GbE modular switch
- An ideal solution for modern workloads and applications designed for the open networking era

Optimized for the open networking era

Get more agility, more choices and lower costs than proprietary networks with select open-standards-based ON (open networking) switches.

- Disaggregated-hardware/software solutions bring new levels of freedom and flexibility to your data center.
- Support for Open Network Install Environment (ONIE) enables zero-touch installation of alternate network operating systems.
- Your choice of network operating system helps simplify data-center fabric orchestration and automation.
- A broad ecosystem of open-source and Linux-based applications and tools provides more options to optimize and manage your network.

Ready for software-defined networking

Deploy modern workloads and applications while providing an easy on-ramp to software-defined networking (SDN).

- Support for OpenFlow v1.3 provides interoperability with industry-standard OpenFlow controllers.
- VXLAN Layer 2 Gateway enabling allows connection to hypervisor-based overlay networks.
- Third-party OS support provides an easy entry point to SDN for part or all of your production environment.

Dell EMC Networking S5248F-ON

Provide optimum flexibility and cost-effectiveness for demanding compute and storage traffic environments with this ToR switch that features 48 x 25GbE SFP28 ports, 4 x 100GbE QSFP28 ports and 2 x 100GbE QFSP28-DD ports. The S5248F-ON also supports Open Network Install Environment (ONIE) for zero-touch installation of network operating systems.

Description

Flexible architectural agility
Designed for architectural agility and flexibility to help data centers smoothly migrate to a software-designed data center.

Specifications

Management features
Switch type	Managed
Quality of Service (QoS) support	Yes
Multicast support	Yes
Switch layer	L2/L3
Ports & interfaces
SFP module slots quantity	48
Basic switching RJ-45 Ethernet ports quantity	0
Basic switching RJ-45 Ethernet ports type	No
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Fiber optic connector	QSFP-DD, QSFP28-DD, QSFP28, SFP28
Console port	RJ-45
Power connector	AC-in jack
Switching optical modules type	100 Gigabit Ethernet
Network
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3x
VLAN support	Yes
Port mirroring	Yes
Link aggregation	Yes
10G support	Yes
Address Resolution Protocol (ARP) entries (max)	128000
Virtual LAN features	Tagged VLAN
Optical fiber
Switching optical modules type	100 Gigabit Ethernet
Fiber optic connector	QSFP-DD, QSFP28-DD, QSFP28, SFP28
Data transmission
Packet buffer memory	32 MB
MAC address table	16000 entries
Switching capacity	2000 Gbit/s
Security
Security algorithms	802.1x RADIUS, AES, EAP
Multicast features
Multicast support	Yes
Protocols
Management protocols	CLI, SNMP, REST, API’s
Design
Display type	LED
Backlight display	Yes
Form factor	1U
Product colour	Black
Stackable	Yes
LED indicators	Yes
Cable management	Yes
Rack mounting	Yes
Number of fans	4 fan(s)
Certification	RoHS
Performance
Minimum system requirements	Linux Kernel 4.9
Internal memory	16000 MB
Compatible operating systems	Debian Linux version 9
List of RFCs	IP, IPv4, IPv6, RIP, OSPF, IS-IS, BGP
Built-in processor	Yes
Packet buffer memory	32 MB
Stackable	Yes
Harmonized System (HS) code	85176990

Power
Power consumption (max)	602 W
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	400 W
Redundant power supply (RPS) support	Yes
Number of power supply units	2
Power connector	AC-in jack
Power over Ethernet (PoE)
Power over Ethernet (PoE)	No
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 90%
Heat dissipation	2054 BTU/h
Virtual LAN features
VLAN support	Yes
Virtual LAN features	Tagged VLAN
Weight & dimensions
Width	434 mm
Depth	460 mm
Height	44 mm
Weight	9.7 kg
Technical details
Form factor	1U
Product colour	Black
Stackable	Yes
Cable management	Yes
Rack mounting	Yes
Built-in processor	Yes
List of RFCs	IP, IPv4, IPv6, RIP, OSPF, IS-IS, BGP
Memory
Packet buffer memory	32 MB
Internal memory	16000 MB
Certificates
Certification	RoHS
Indication
LED indicators	Yes
System requirements
Minimum system requirements	Linux Kernel 4.9
Compatible operating systems	Debian Linux version 9
Logistics data
Harmonized System (HS) code	85176990
