iiyama ProLite T1634MC-B1S computer monitor 39.6 cm (15.6") 1920 x 1080 pixels Full HD LED Touchscreen Black
SKU
T1634MC-B1S
Login for pricing
15.6", 39.5cm, IPS, LED, 1920 x 1080, 16:9, 450 cd/m², 90%, 25ms, 381 x 285.5 x 200mm, 445 x 355 x 150mm, 3.4kg, 5.18kg
IPS Technology
IPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.
Touch Through-Glass
This through glass touch screen works right through glass and can turn glass surfaces into an interactive touch screen display. Use it on storefront windows, real estate office, in-store for POS or restaurants.
Touch technology - Capacitive
This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.
Full HD
With true 1920 x 1080p resolution your monitor is ready to display high definition images. This means you can accommodate more information on your screen; e.g. 60% more in comparison to a 1280 x 1024 monitor.
IP65
The IP code classifies and rates the degree of protection against water intrusion. IP65 means that the monitor is protected to water splashes against the enclosure from any direction.
15.6" Full HD PCAP 10 point touch monitor with edge-to-edge glass, IPS Panel Technology and touch through glass function
The ProLite T1634MC-B1S uses projective capacitive touch technology, built into an eye catching bezel with edge-to-edge glass. Featuring IPS Panel Technology and Full HD (1920x1080) resolution, it offers natural, highly accurate colours and wide viewing angles. The flexible stand can be positioned at several angels creating a comfortable and ergonomic user experience and the integrated cable management system hides all the cables and electrical wires giving a neat and cable-free workspace. In addition to the superb image quality, the screen comes with an IP65 rating, which means the screen and bezel is totally dust and water resistant, making it a perfect solution for demanding environments. The Touch-Through-Glass function guarantees a seamless and accurate touch response for interactive behind-glass-retail applications.
The ProLite T1634MC-B1S uses projective capacitive touch technology, built into an eye catching bezel with edge-to-edge glass. Featuring IPS Panel Technology and Full HD (1920x1080) resolution, it offers natural, highly accurate colours and wide viewing angles. The flexible stand can be positioned at several angels creating a comfortable and ergonomic user experience and the integrated cable management system hides all the cables and electrical wires giving a neat and cable-free workspace. In addition to the superb image quality, the screen comes with an IP65 rating, which means the screen and bezel is totally dust and water resistant, making it a perfect solution for demanding environments. The Touch-Through-Glass function guarantees a seamless and accurate touch response for interactive behind-glass-retail applications.
| Display | |
|---|---|
| HDCP | Yes |
| Display brightness (typical) | 405 cd/m² |
| Screen shape | Flat |
| Display number of colours | 16.2 million colours |
| Native aspect ratio | 16:9 |
| Colour gamut | 90% |
| Maximum refresh rate | 60 Hz |
| Display surface | Matt |
| HD type | Full HD |
| Display technology | LED |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.179 x 0.179 mm |
| Digital horizontal frequency | 30 - 84 kHz |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 39.6 cm (15.6") |
| Contrast ratio (typical) | 700:1 |
| Response time (fast) | 25 ms |
| Display brightness (peak) | 450 cd/m² |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Panel type | IPS |
| Colour depth | 6 bit |
| Display diagonal (metric) | 39.5 cm |
| Touchscreen technology | Projected capacitive system |
| Second display effective viewing area | 344.2 x 193.6 mm |
| Management features | |
| On Screen Display (OSD) | Yes |
| Design | |
| Market positioning | Office |
| Product colour | Black |
| International Protection (IP) code | IP65 |
| Glass thickness | 2.4 mm |
| Ports & interfaces | |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| HDCP | Yes |
| HDMI | Yes |
| Technical details | |
| HDMI | Yes |
| Product colour | Black |
| Power supply type | External |
| Weight (with stand) | 3.4 kg |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
| Ergonomics | |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Tilt angle range | 90 - 5° |
| On Screen Display (OSD) | Yes |
| Tilt adjustment | Yes |
| Power | |
|---|---|
| Power supply type | External |
| Power consumption (standby) | 1.5 W |
| Power consumption (typical) | 18 W |
| Power consumption (off) | 0.3 W |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 10 kWh |
| European Product Registry for Energy Labelling (EPREL) code | 1530736 |
| Weight & dimensions | |
| Width (with stand) | 381 mm |
| Depth (with stand) | 200 mm |
| Height (with stand) | 285.5 mm |
| Weight (with stand) | 3.4 kg |
| Package width | 445 mm |
| Package depth | 150 mm |
| Package height | 355 mm |
| Package weight | 5.18 kg |
| Packaging data | |
| Package width | 445 mm |
| Package depth | 150 mm |
| Package height | 355 mm |
| Package weight | 5.18 kg |
| Cables included | AC, DisplayPort, HDMI, USB |
| Packaging content | |
| Cables included | AC, DisplayPort, HDMI, USB |
| Sustainability | |
| European Product Registry for Energy Labelling (EPREL) code | 1530736 |
| Other features | |
| International Protection (IP) code | IP65 |
| Second display effective viewing area | 344.2 x 193.6 mm |
| HDMI | Yes |
| Energy efficiency scale | A to G |
| Power supply type | External |
| Display brightness (peak) | 450 cd/m² |
| Touchscreen | Yes |
| Number of simultaneous touchpoints | 10 |
